| Camera |
| Image Sensor: |
1/1.8" Progressive Scan CMOS |
| Signal System: |
PAL/NTSC |
| Min. Illumination: |
Color: 0.002 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter time: |
1 s to 1/100,000 s |
| Slow shutter: |
Yes |
| Lens: |
8-32mm |
| Adjustment Range: |
Bracket, pan: 0° to 355°, tilt: 0° to 90°, rotate 0° to 360° |
| Day& Night: |
IR Cut Filter |
| Wide Dynamic Range: |
140dB |
| Digital noise reduction: |
3D DNR |
| Focus: |
Motorized VF lens(-Z model) |
| Compression Standard |
| Video Compression: |
H.265+/H.265/H.264+/H.264/MJPEG |
| H.264 code profile: |
Baseline Profile/Main Profile/High Profile |
| Video bitrate: |
32Kbps~16Mbps |
| Audio bitrate: |
No |
| Dual Stream: |
Yes |
| Triple Streams: |
Yes |
| Image |
| Max. Image Resolution: |
1920 x 1080 |
| Sub Stream: |
50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480) |
| Frame Rate: |
50Hz: 50fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 60fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Third Stream: |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480) |
| Image Enhancement: |
BLC, HLC, 3D DNR, Defog, EIS |
| Image Settings: |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| Target Cropping: |
Yes |
| BLC: |
Support |
| HLC: |
Support |
| Smart Defog: |
Support |
| EIS: |
Support |
| 3D DNR: |
Support |
| Picture Overlay: |
LOGO picture can be overlaid on video with 128 × 128 24bit BMP format. |
| Day/Night Switch: |
Day/Night/Auto/Schedule/Triggered by Alarm In |
| Network |
| Network Storage: |
Support MicroSD/SDHC/SDXC card (256 GB) local storage and NAS (NFS, SMB/CIFS), ANR |
| Alarm Trigger: |
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Protocols: |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| General Function: |
One-key reset, anti-flicker, five streams and up to 5 custom streams, heartbeat, password protection, privacy mask, watermark, IP address filter |
| System Compatibility: |
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
| Interface |
| Communication Interface: |
1 RJ45 10M/100M/1000M Ethernet port |
| Alarm: |
2 inputs, 2 outputs (up to 24 VDC 1A or 110 VAC 500 mA) |
| On-board storage: |
Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Reset Button: |
Yes |
| Smart Feature-set |
| Behaviour Analysis: |
Line crossing detection, Intrusion detection, Region entrance, Region exiting, Unattended Baggage, Object removal |
| Line Crossing Detection: |
Cross a pre-defined virtual line |
| Intrusion Detection: |
Enter and loiter in a pre-defined virtual region |
| Region Entrance: |
Enter a pre-defined virtual region from the outside place |
| Region Exiting: |
Exit from a pre-defined virtual region |
| Unattended Baggage: |
Objects left over in the pre-defined region such as the baggage, purse, dangerous materials |
| Object Removal: |
Objects removed from the pre-defined region, such as the exhibits on display. |
| Exception Detections: |
Scene change detection, Sudden audio increase/decrease detection, Audio loss detection, Defocus detection |
| Recognition: |
Face Detection |
| Statistics: |
Object Counting (Entrance and Exit object number is accounted and showed on screen in real time) |
| General |
| Operation Condition: |
-30 °C to 65 °C (-22 °F to 149 °F), -H: -40 °C to 65 °C (-40 °F to 149 °F)
Humidity 95% or less (non-condensing) |
| IR Range: |
2.8-12mm:50m
8-32mm:100m |
| Power Supply: |
12 V DC ± 20%, PoE (802.3at, class 4) |
| Power Consumption: |
-IZS: 12 VDC, 1.0 A, max. 12 W; PoE (802.3at, 42.5 V to 57 V), 0.3 A to 0.2 A
-IZHS: 12 VDC, 1.3 A, max. 15 W; PoE (802.3at, 42.5 V to 57 V), 0.4 A to 0.3 A |
| Impact Protection: |
IK10 |
| Weather Proof: |
IP67 |
| Dimensions: |
camera: Φ144 × 347 mm (Φ5.7″ × 13.7″)
With package: 405 × 190 × 180 mm (15.9″ × 7.5″ × 7.1″) |
| Weight: |
Camera: approx. 2.45 kg (5.40 lb.)
With package: approx. 2.7 kg (5.95 lb.) |
| Video/Audio Input |
| Audio Input: |
4-ch |
| Video Compression: |
H.264 |
| Analog and HD-TVI video input: |
4-ch,BNC interface (1.0Vp-p, 75 Ω) |
| Supported camera types: |
720P25, 720P30, 720P50, 720P60, 1080P25, 1080P30, CVBS |
| IP Video Input: |
2-ch 1080P |
| Video Input Interface: |
BNC (1.0 Vp-p, 75Ω) |
| Audio Compression: |
G.711u |
| Audio Input Interface: |
RCA (2.0 Vp-p, 1 kΩ) |
| Two-way Audio: |
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the 1st channel of audio input) |
| Video/Audio Output |
| HDMI/VGA Output: |
1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
| Recording resolution: |
Mainstream: 1080P / 720P / VGA / WD1 / 4CIF / CIF;Sub-stream: WD1(non-real-time)
/ 4CIF(non-real-time) / CIF / QCIF / QVGA |
| Frame Rate: |
Mainstream: 1/16 fps ~ Real time frame rate
Sub-stream: 1/16 fps ~ Real time frame rate |
| Video Bit Rate: |
32 Kbps-10 Mbps |
| Audio Output: |
1-ch RCA(Linear, 1kΩ) |
| Audio Bit Rate: |
64kbps |
| Dual Stream: |
Support |
| Playback Resolution: |
1080P / 720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF |
| Synchronous Playback: |
4-ch |
| Network management |
| Remote connections: |
128 |
| Network protocols: |
TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI,
UPnP™, HTTPS |
| Hard Disk Driver |
| Interface Type: |
1 SATA Interface |
| Capacity: |
Up to 6 TB capacity for each disk |
| External Interface |
| Network Interface: |
1; 10M / 100M / 1000M self-adaptive Ethernet interface |
| USB Interface: |
2 USB 2.0 Interfaces |
| Serial Interface: |
1; standard RS-485 serial interface, half-duplex |
| Alarm Input: |
4-ch |
| Alarm Output: |
1-ch |
| General |
| Power Supply: |
12V DC |
| Consumption: |
≤ 15W |
| Working Temperature: |
-10 ºC ~+55 ºC (14 ºF ~ 131 ºF) |
| Working Humidity: |
10% ~ 90% |
| Chassis: |
1U chassis |
| Dimensions: |
315 × 242 × 45mm (12.4 × 9.5 × 1.8 inch) |
| Weight: |
≤ 1.5Kg (3.3lb) |
