| Camera |
|---|
| Image sensor: |
1/1.8” Progressive Scan CMOS |
| Min. illumination: |
0.0027 lux @ (ƒ/1.4, AGC on), 0 lux with IR |
| Shutter time: |
1 s to 1/100,000 s |
| Lens: |
2.8 mm to 12 mm @ F/1.4, 92° to 32° |
| Lens mount: |
Φ14 |
| Angle Adjustment: |
Pan: 0° to 355°, tilt: 0° to 75°, rotation: 0° to 355° |
| Auto iris: |
DC drive |
| Day & night: |
IR cut filter with auto switch |
| Digital noise reduction: |
3D DNR |
| Wide dynamic range: |
120 dB |
| Smart Focus: |
Yes |
| Compression standard |
|---|
| Video compression: |
H.264+ / H.264 / MJPEG / MPEG 4 |
| H.264 codec profile: |
Baseline Profile / Main Profile / High Profile |
| Video bit rate: |
32 Kbps – 16 Mbps |
| Audio compression: |
G.711/G.722.1/G.726/MP2L2 |
| Audio bit rate: |
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 128 Kbps (MP2L2) |
| Image |
|---|
| Max. resolution: |
1920 × 1080 |
| Frame rate: |
30 fps (1920 × 1080, 1280 × 960, 1280 x 720) |
| 3rd stream: |
Independent with main stream and sub stream, up to 50 Hz: 25 fps (1920 × 1080);
60 Hz: 30 fps (1920 × 1080) |
| BLC: |
Supported, zone optional |
| Defog: |
Supported |
| ROI: |
Supported |
| Day/Night Switch: |
Auto/Schedule/Triggered by Alarm In |
| Picture Overlay: |
24-bit BMP format overlay, zone optional |
| Network |
|---|
| Network storage: |
MicroSD/SDHC/SDXC card with ANR (up to 128 GB), NAS (Supports NFS,
SMB/CIFS) |
| Alarm trigger: |
Line crossing detection, intrusion detection, scene change detection, audio
exception
detection, motion detection, dynamic analysis, tampering alarm, network
disconnect,
IP address conflict, storage exception |
| Protocols: |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP,
PPPoE,
NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Security: |
One-key recovery, flash-prevention, three streams, heartbeat, mirror, password
protection, video mask,
Watermark, IP address filtering, anonymous access |
| System compatibility: |
ONVIF, PSIA, CGI, ISAPI |
| Interface |
|---|
| Audio input: |
1-ch 3.5 mm audio interface, mic in/line in |
| Audio output: |
1-ch 3.5 mm audio interface |
| Communication interface: |
1 RJ-45 10M/100M Ethernet port, 1 RS-485 interface |
| Alarm I/O: |
1/1 |
| Video output: |
1 Vp-p composite output (75 Ω/BNC) |
| On-board storage: |
Built-in microSD/SDHC/SDXC slot, up to 128 GB |
| Reset: |
Yes |
| General |
|---|
| Operating conditions: |
-40° C to 60° C, humidity 95% or less (non-condensing) |
| Power supply: |
12 VDC/24 VAC/PoE+ (802.3at) |
| Power consumption: |
Max: 17 W |
| IR range: |
40 meters (43.75 yards) |
| Impact protection: |
IK10 |
| Dimensions: |
Φ164.9 mm × 127 mm (Φ6.49" × 5") |
| Weight: |
2100 g (4.62 lbs.) |
